Product: 5636K, 3M™ Cold Shrink QT-II Termination Kit , Tape, Wire and UniShield®, 5-15 kV, 1.10-1.65 in (28-42 mm) Cable Insul. O.D., 3 terminations/kit
Ref. Catalog: 5636K
Brand: 3M
Category: Electrical & Termination kit
Dimension: cm (39 x 21 x 22)
Weight: g (1750)
Price: 32,284.00
Stocks: 1
Add to cartProvides a void-free seal to tape shield, wire shield and UniShield® power cables High dielectric-constant material regulates the distribution of electric field stress Suitable for outdoor, weather exposed applications Silicone rubber insulation is track-resistance and hydrophobic Silicone cold shrink application provides constant radial pressure, "living seal" Withstands voltages of 5 to 15kV and is 110 kV BIL-rated Meets IEEE Standard 48, Class 1 for outdoor, weather-exposed applications Meets IEEE Standard 48, Class 1 for outdoor, weather-exposed applications
3M™ Cold Shrink QT-II 5630K Series Termination Kit includes three 4-skirt, 1-piece terminations. It ensures a pliable, tight seal for tape shield, wire shield and UniShield® power cables. The conjunction of high dielectric-constant material and silicone rubber insulation allows the termination to withstand voltages of 5 to 15kV.
- Provides a void-free seal to tape shield, wire shield and UniShield® power cables
- High dielectric-constant material regulates the distribution of electric field stress
- Suitable for outdoor, weather exposed applications
- Silicone rubber insulation is track-resistance and hydrophobic
- Silicone cold shrink application provides constant radial pressure, "living seal"
- Withstands voltages of 5 to 15kV and is 110 kV BIL-rated
- Meets IEEE Standard 48, Class 1 for outdoor, weather-exposed applications
- Meets IEEE Standard 48, Class 1 for outdoor, weather-exposed applications
