Poles description: 2P Protected poles description: 2t Network type: DC, AC Network frequency: 50/60 Hz [In] rated current: 100 A at 40 °C [Ui] rated insulation voltage: 690 V AC 50/60 Hz conforming to IEC 60947-2 [Uimp] rated impulse withstand voltage: 6 kV conforming to IEC 60947-2 [Ue] rated operational voltage: 550 V AC 50/60 Hz conforming to IEC 60947-2 250 V DC conforming to IEC 60947-2 Breaking capacity code: H Breaking capacity: 10 kA Icu at 125 V DC 1P conforming to IEC 60947-2 10 kA Icu at 250 V DC 2P conforming to IEC 60947-2 10 kA Icu at 550 V AC 50/60 Hz conforming to IEC 60947-2 100 kA Icu at 110...130 V AC 50/60 Hz conforming to IEC 60947-2 20 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2 30 kA Icu at 380 V AC 50/60 Hz conforming to IEC 60947-2 30 kA Icu at 400...415 V AC 50/60 Hz conforming to IEC 60947-2 50 kA Icu at 220...240 V AC 50/60 Hz conforming to IEC 60947-2 [Ics] rated service breaking capacity: 15 kA at 380 V AC 50/60 Hz conforming to IEC 60947-2 5 kA at 125 V DC conforming to IEC 60947-2 5 kA at 250 V DC conforming to IEC 60947-2 50 kA at 110/130 V AC 50/60 Hz conforming to IEC 60947-2 5 kA at 440 V AC 50/60 Hz conforming to IEC 60947-2 2.5 kA at 550 V AC 50/60 Hz conforming to IEC 60947-2 7.5 kA at 400/415 V AC 50/60 Hz conforming to IEC 60947-2 25 kA at 220/230/240 V AC 50/60 Hz conforming to IEC 60947-2 Suitability for isolation: Yes conforming to IEC 60947-2 Utilisation category: Category A Trip unit name: TM-D Trip unit technology: Thermal-magnetic Trip unit rating: 80 A at 50 °C Protection type: Overload protection, Short-circuit protection Pollution degree: 3 conforming to IEC 60664-1, 3 conforming to IEC 947-1
