AvatarOn A 1 gang Grid Plate - WHITE (M3T01_WE) 𝗦𝗣𝗘𝗖𝗜𝗙𝗜𝗖𝗔𝗧𝗜𝗢𝗡𝗦 • range of product: AvatarOn A • product or component type: Grid plate • number of gangs: 1 gang • colour tint: White Complementary • material: PC: grid plate • PC: side panels • device mounting: Flush Environment • ambient air temperature for operation: -5…45 °C • relative humidity: 0…95 % 𝗗𝗜𝗠𝗘𝗡𝗦𝗜𝗢𝗡𝗦 • width: 120 mm • height: 70 mm • depth: 22.7 mm AvatarOn A 16A 250V 1G 2 Pin Universal Socket-outlet S-size White (M3T426US_WE) 𝗦𝗣𝗘𝗖𝗜𝗙𝗜𝗖𝗔𝗧𝗜𝗢𝗡𝗦 Main • range of product: AvatarOn A • product or component type: Socket-outlet • device presentation: Complete product • colour tint: White • outlet poles configuration: 2P Complementary • rated current: 16 A at 250 V AC 50...60 Hz • socket number: 1 • clamping connection capacity • 2 x 1.5...2 x 4 mm² for solid cable(s) • 2 x 1.5...2 x 4 mm² for stranded cable(s) • connections - terminals: Screwless terminals • material • Polycarbonate cover • Polycarbonate base • device mounting: Flush • width: 23.1 mm • height: 69.3 mm • depth: 36.35 mm • embedding depth: 24.85 mm Environment • IP degree of protection: IP20 • maximum ambient air temperature for operation: 35 °C • ambient air temperature for storage: -5…45 °C • relative humidity: 0…95 % • operating altitude: < 2000 m • standards: IEC 60884-1 • product certifications: IEC
