Product: EZC100H2020 - Moulded Case Circuit Breaker 2Poles 20amps
Ref. Catalog: EZC100H2020
Brand: Schneider Electric
Category: Power Distributions
Dimension: cm (6 x 10 x 14)
Weight: g (559)
Price: 2,502.00
Stocks: 1
Add to cartSchneider Electric EasyPact EZC, EZC100 H 30kA 2P/2T 20A
- -20A, 30kA 2P/2T, 2 Pole
- -Breaking capacity up to 50 kA at 400/415 V
- -Thermal-magnetic for the entire range
- -Complete range of auxiliaries: rotary commands, auxiliaries, shunt trip, phase barrier, terminal cover, undervoltage trip
- -Built-in integrated earth-leakage protection (EZC 250 ELCB)
- -Compliance with international standards: IEC 60947-1 and 2, CCC, EAC and other local certifications
- -Green Premium product
